Each screen shade comes with a visible roll. Upgrade to an aluminum fascia valance or our elegant fabric wrapped fascia valance.
Environmental Certification: GREENGUARD Indoor Air Quality Certified for low emissions (LEED™)GREENGUARD for Children and Schools Certified
Fire Classification: California U.S. Title 19 (small scale), NFPA 701-1999 TM#1 (small scale), NFPA 101 (Class A Rating), UBC (Class I), and BS 5867
Bacteria & Fungal Resistance: ASTM-G21, ASTM-G22
Standard Roller
Inside Mount
bracket to bracket, ordered width
End to end, ordered width minus 1 1/16"
Fabric width, ordered width minus 1 1/4"
Outside Mount
bracket to bracket, ordered width plus 3/16"
End to end, ordered width minus 7/8"
Fabric width, ordered width minus 1 1/16"
Cassette Headrail
Inside Mount
Headrail width, ordered width minus 3/8"
Fabric width, ordered width minus 1 1/8"
Outside Mount
headrail width, ordered width plus 3/16"
Fabric width, ordered width minus 3/4"
Motorization is Z-Wave compatible.
Product Details
Light Control
Light Filtering
Helpful tip:
Dark fabrics offer the best views. Light fabrics offer the most protection from the sun’s heat and UV rays.
Fabric Gap (Deductions):
Light Gap by Side & Lift Control
9/16" on Chain side; 7/16" other side (1" Total) - Continuous Cord Loop
3/4" on Chain side; 5/8" other side (1 3/8" Total) - Continuous Cord Loop w/ Cassette
5/8" (1 1/4" Total) - Cordless
5/8" (1 1/4" Total) - Cordless w/ Cassette
9/16" on Motor side; 7/16" other side (1" Total) - Motorized
3/4" on Motor side; 7/16" other side (1 1/16" Total) - Motorized w/ Cassette
Measure & Install
How To Measure
How To Install
Professional
Measuring & Installation
General Specifications
Width:
15" - 118"
Height:
15" - 118"
Minimum Mounting Depth:
2.5"
Minimum Flush Mounting Depth:
3.25"
Continuous Cord Loop
This lift option has a looping lift chain adjacent to the shade. The fabric/material is narrower on the control side allowing the control to hang to the side without interfering with the lift of the shade. Shades with Continuous Cord Loop option may have a light gap on black-out shades.
Cordless Lift
Raise and lower your blinds without cords. This upgrade is great for homes with children because there are no dangerous lift cords. Not recommended for sizes wider than 96 inches.
Width:
20" - 84"
Height:
12" - 96"
Motorization
Make sure to order at least one remote or smart hub to control your motorized shades. One remote can operate more than one shade. Raise and lower your window shades with the touch of a finger. Our remote controlled shades use a radio technology system.
Width:
14" - 96"
Height:
18" - 96"
Power Type:
AA lithium battery packs (included)
Battery Life Expectancy:
1 - 2 years
Control Options:
Remote Control or Wireless Wall Switch - must order at least 1 remote control
Compatible with Smart Home Devices:
No
Z-wave Compatible:
No
Square Aluminum Fascia Valance
3" and 4" square aluminum fascia is made from an "L" shaped aluminum extrusion, covering the bottom and front of the roller. Valance snaps into brackets and fittings concealing the roller.
Size varies based on the roller thickness or length of the shade. Available in standard roll only, not available in reverse roll.
Size varies based on the roller thickness or length of the shade. Available in standard roll only, not available in reverse roll.
Width:
18" - 118"
Height:
12" - 156"
Minimum Mounting Depth:
1 5/8"
Minimum Flush Inside Mounting Surface:
3 7/8"
Guaranteed to Fit
Let us take the worry out of measuring with our Guaranteed to Fit protection. If your blind doesn't fit we will remake it for you.
If you make a mistake, we've got you covered. learn more
If you make a mistake, we've got you covered. learn more
Remote - 1 Channel
Control a single window shade or a group of window shades at ONCE. Single channel remote will only operate multiple shades together, not individually.
Remote - 5 Channel
Control up to 5 window shades or 5 groups of window shades with the same remote.
Timer
Wall Switch - 1 Channel
Works just like a wall switch. Control up to 1 window shades or 1 groups of window shades. The switch is easy to install with a standard electrical box. No wiring is needed. Remote runs off battery.
Wall Switch - 5 Channel
Works just like a wall switch. Control up to 5 window shades or 5 groups of window shades. The switch is easy to install with a standard electrical box. No wiring is needed. Remote runs off battery.
Free Features
Lift Cord
The lift cord is used to raise and lower the blinds. This option allows you to select the position of the cord on the blinds.
Roll Type
The side in which the fabric comes of the roll and whether the roll is visible. With the standard roll, the fabric comes down behind the roll next to the wall and the roll is visible inside the house. This option keeps the fabric tight to the wall on an outside mount. Reverse roll brings the fabric down in front of the roll and hides the roll from the house side of the roller shade.
