Product Details
Light Control
Light Filtering
Lift Options:
Color Coordinated Plastic Beaded Chain Loop or Cordless
Mounting Details:
Chain Loop lift can be top and back mounted.
Fabric Gap (Deductions):
Light Gap by Side & Lift Control
9/16" on Chain side; 7/16" other side (1" Total) - Continuous Cord Loop
3/4" on Chain side; 5/8" other side (1 3/8" Total) - Continuous Cord Loop w/ Cassette
5/8" (1 1/4" Total) - Cordless
5/8" (1 1/4" Total) - Cordless w/ Cassette
5/8" (1 1/4" Total) - Cordless LuxLift
5/8" (1 1/4" Total) - Cordless LuxLift w/ Cassette
9/16" on Motor side; 7/16" other side (1" Total) - Motorized
3/4" on Motor side; 7/16" other side (1 1/16" Total) - Motorized w/ Cassette
9/16" on Motor side; 7/16" other side (1" Total) - Wand Motorization
3/4" on Motor side; 7/16" other side (1 1/16" Total) - Wand Motorization w/ Cassette
Measure & Install
How To Measure
How To Install
Professional
Measuring & Installation
General Specifications
Width:
15" - 96"
Height:
24" - 110"
Minimum Mounting Depth:
2.25"
Minimum Flush Mounting Depth:
3"
Continuous Cord Loop
This lift option has a looping lift chain adjacent to the shade. The fabric/material is narrower on the control side allowing the control to hang to the side without interfering with the lift of the shade. Shades with Continuous Cord Loop option may have a light gap on black-out shades.
Cordless Lift
Raise and lower your blinds without cords. This upgrade is great for homes with children because there are no dangerous lift cords. Not recommended for sizes wider than 96 inches.
Width:
15" - 83"
Height:
24" - 84"
Minimum Mounting Depth:
2 1/4"
Minimum Flush Mounting Depth:
3"
Mounting Details:
Top or rear mounted.
Inside Mount Fabric Gap:
9/16" per side mounted.
Other:
Cassette not available.
Installation:
Notes:
Does NOT include bracket covers.
Cordless LuxLift
Cordless LuxLift allows for precise shade positioning with the innovative one-touch technology that ensures quick, accurate control without cords or tugging. Easily adjust light and privacy levels with a simple touch and effortlessly position shades to your liking, from the smallest to largest of sizes.
Width:
24" - 72"
Height:
24" - 72"
Minimum Mounting Depth:
2 5/8"
Flush Mounting Depth:
3 1/4"
Bluetooth Motorization
Make sure to order at least one remote or smart hub to control your motorized shades. One remote can operate more than one shade. Raise and lower your window shades with the touch of a finger. Our remote controlled shades use a radio technology system.
Width:
23" - 96"
Height:
24" - 96"
Minimum Mounting Depth:
2 1/4" standard no cassette.
2 5/8" with Cassette.
2 5/8" with Cassette.
Power Type
Rechargeable Battery
Approx. Operations per Charge
Up to 1 year
Control Options
Use Phone as Remote - download the free Home Life app on your mobile device from the IOS App Store or Google Play to operate the shades.
Remote Control - must order at least 1 remote control.
Voice Control - Smart Home must be added.
Tablet or Phone Control - Smart Home Hub must be added.
Remote Control - must order at least 1 remote control.
Voice Control - Smart Home must be added.
Tablet or Phone Control - Smart Home Hub must be added.
Compatible with Smart Home Devices
Yes - Smart Home Hub must be added
Z-wave Compatible
No
Installation:
Wand Motorization
The wand motorization is ideal for child safety with no lift cords. With the press of a button raise and lower the shades with ease. Simply press and hold the button to raise or lower the shades and release to stop at the desired position. The wand motorization operates with a battery powered motor.
Width:
20" - 96"
Height:
24" - 110"
Power Source:
Rechargeable battery. USB-C charging.
Battery Life Expectancy:
1 year (about 500 operation cycles)
Color:
White
Cassette Headrail
The cassette headrail comes with a matching fabric strip.
Width:
15" - 96"
Height:
24" - 96"
Headrail Dimension:
3 1/4" x 3"
Minimum Mounting Depth:
2 5/8"
Minimum Flush Mounting Depth:
3 5/8"
Mounting Details:
Top or Wall Mounted only
Headrail Measurement:
Headrail:
Inside mount, ordered width minus 3/8"
Outside mount, ordered width plus 3/16"
Inside mount, ordered width minus 3/8"
Outside mount, ordered width plus 3/16"
Guaranteed to Fit
Let us take the worry out of measuring with our Guaranteed to Fit protection. If your blind doesn't fit we will remake it for you.
If you make a mistake, we've got you covered. learn more
If you make a mistake, we've got you covered. learn more
No Remote - Use Phone as Remote
A free motorization app you can downloaded on your mobile device from the IOS App Store or Google Play to operate the shades. Please note that you must be within range to operate the shades with phone. The app will vary by product, please see Bluetooth Motorization specifications below for the App used.
Remote - 1 Channel
Control a single window shade or a group of window shades at ONCE. Single channel remote will only operate multiple shades together, not individually.
Remote - 16 Channel
Control up to 16 individual shades or groups of shades on one remote control.
HomeMate Smart Home Hub
Adding a Smart Home Hub to motorized blinds allows you to connect your window coverings to your smart home such as Alexa or Google Home. One Smart Home Hub system will allow you to control multiple blinds and in most cases your entire home depending on your home size.
We also recommend ordering at least one remote as well with your blinds for configuration purposes.
We also recommend ordering at least one remote as well with your blinds for configuration purposes.
Brand
HomeMate
Mobile App
HomeMate
Amazon Alexa Compatible
Yes
Google Home Compatible
Yes
Apple HomePod Compatible:
Yes
Other
Requires strong WiFi connection
Free Features
Lift Cord
The lift cord is used to raise and lower the blinds. This option allows you to select the position of the cord on the blinds.
Roll Position
The side in which the fabric comes of the roll and whether the roll is visible. With the standard roll, the fabric comes down behind the roll next to the wall and the roll is visible inside the house. This option keeps the fabric tight to the wall on an outside mount. Reverse roll brings the fabric down in front of the roll and hides the roll from the house side of the roller shade.
