Helpful tip: Dark fabrics offer the best views. Light fabrics offer the most protection from the sun’s heat and UV rays.
If you are interested in a specific Bali Solar Shade color and do not see it listed here, please do not hesitate to contact us to see if it is available.
Environmental Certification
GREENGUARD Indoor Air Quality Certified for low emissions (LEED™)
Looking for more styles? See our full selection of
custom Solar Screen Shades
or browse our entire lineup of Bali brand window treatments.
Product Details
Light Control
Light Filtering
Lift Options
Color Coordinated Plastic Beaded Chain Loop or Cordless
Street Side Color
Same front and back
Mounting Details
3/4" Minimum Inside/Side Mount
4 1/8" Minimum Inside/Top Mount
4 1/8" Minimum Inside/Top Mount
Fabric Gap (Deductions)
Light Gap per Side by Lift Control
7/8" (1 3/4" Total) - Continuous Cord Loop
9/16" (1 1/8" Total) - Continuous Cord Loop w/ Cassette
7/8" (1 3/4" Total) - Continuous Cord Loop w/ 5" Flat Valance
7/8" (1 3/4" Total) - Continuous Cord Loop w/Contour Fabric Valance
3/8" (3/4" Total)- EasyTouch Cordless
1/2" (1" Total) - EasyTouch Cordless w/ Cassette
3/8" (3/4" Total) - EasyTouch Cordless w/ 5" Flat Valance
3/8" (3/4" Total)- EasyTouch Cordless w/Contour Fabric Valance
1/2" (1" Total) - EasyTouch Dual Lift
1/2" (1" Total) - EasyTouch Dual Lift w/ Cassette
1/2" (1" Total) - EasyTouch Dual Lift w/ 5" Flat Valance
1/2" (1" Total) - EasyTouch Dual Lift w/Contour Fabric Valance
1/2" (1" Total) - Motorized
1/2" (1" Total) - Motorized w/ Cassette
1/2" (1" Total) - Motorized w/ 5" Flat Valance
1/2" (1" Total) - Motorized w/Contour Fabric Valance
Sample Booklet
GreenGuard® Certified
Measure & Install
How To Measure
How To Install
Professional
Measuring & Installation
General Specifications
Width
12" - 116"
Height
12" - 108"
Minimum Mounting Depth
3/4"
Continuous Cord Loop
This lift option has a looping lift cord adjacent to the shade. The fabric/material is narrower on the control side allowing the control to hang to the side without interfering with the lift of the shade. Shades with Continuous Cord Loop option may have a light gap on black-out shades.
EasyTouch Cordless Lift
Cordless lift system with precision placement - raise and lower the shade by moving the hem bar exactly where you want it. Clear hem grip included. Aesthetically beautiful mounting hardware that hides mechanicals. A safer alternative for homes with children or pets.
Width
12" - 78"
Height
12" - 108"
Minimum Mounting Depth
3/4" Side Mount
2 1/8" Top Mount
Minimum Flush Mounting Depth
3 3/4"
Inside Mount Fabric Gap
3/8" per side
Installation
EasyTouch Dual Lift
A lift system with two ways to operate the shade - raise and lower the shade by moving the hem bar exactly where you want it, or raise and lower using the cord. A safety cord guide provides the ability to keep the cord out of the reach of children and pets to enhance safety.
Width
12" - 78"
Height
12" - 108"
Minimum Mounting Depth
3/4" Side Mount
2 1/8" Top Mount
Minimum Flush Mounting Depth
3 3/4"
Inside Mount Fabric Gap
1/2" per side
Bluetooth Motorization
Make sure to order at least one remote or smart hub to control your motorized shades. One remote can operate more than one shade. Raise and lower your window shades with the touch of a finger. Our remote controlled shades use a radio technology system.
Width
16" - 72"
Height
13" - 80"
Headrail Dimension
Standard, no cassette: 4 1/8" D x 4 1/2" L
Cassette: 4 1/4" D x 3 5/8" L
Cassette: 4 1/4" D x 3 5/8" L
Minimum Mounting Depth
Standard, no cassette: 3/4" Inside Side mount and 4 1/8" Inside Top mount.
Cassette: 1 3/4"
Cassette: 1 3/4"
Minimum Flush Mounting Depth
Standard, no cassette: 4 1/8"
Casssette: 4 1/4"
Casssette: 4 1/4"
Power Type
Rechargeable Battery Pack.
Dimensions: 8 9/16" x 1 7/16" x 15/16"
The rechargeable battery pack comes as a sealed pack with the batteries already included.
Batteries are charged by plugging the charger into the pack.
Battery packs ship at 30% charge and must be fully charged prior to installation.
Dimensions: 8 9/16" x 1 7/16" x 15/16"
The rechargeable battery pack comes as a sealed pack with the batteries already included.
Batteries are charged by plugging the charger into the pack.
Battery packs ship at 30% charge and must be fully charged prior to installation.
Battery Box Location
Battery cases are installed in space outside of the product and can be a challenge to hide in some windows.
For Inside Mounts: The cleanest and simplest method available is the integrated battery case hanger; this hanger attaches directly to a shade bracket to support the battery case while allowing the case to be removed for battery changes; additional recessed space will be needed.
For Outside Mounts: Battery cases can be installed above or to the side of the shade.
For Inside Mounts: The cleanest and simplest method available is the integrated battery case hanger; this hanger attaches directly to a shade bracket to support the battery case while allowing the case to be removed for battery changes; additional recessed space will be needed.
For Outside Mounts: Battery cases can be installed above or to the side of the shade.
Estimated Battery Life
6 - 12 months.
Larger shades consume more power while operating.
Larger shades consume more power while operating.
Control Options
Use Phone as Remote - Bali has a free motorization app you can download on your mobile device from the IOS App Store or Google Play to operate the shades.
Remote Control - must order at least 1 remote control
Voice Control - Smart Home Hub must be added
Tablet or Phone Control - Smart Home Hub must be added
Remote Control - must order at least 1 remote control
Voice Control - Smart Home Hub must be added
Tablet or Phone Control - Smart Home Hub must be added
Z-wave Compatible
Yes
Compatible with Smart Home Devices
Yes
Installation
5" Flat Valance
A modern 5" fabric-wrapped flat valance. Spline and returns are color coordinated. Valance fabric is not orientated to the shade fabric (e.g., on a patterened
fabric, the pattern of the shade fabric and that of the valance fabric will not necessarily align)
fabric, the pattern of the shade fabric and that of the valance fabric will not necessarily align)
Width
12" - 84"
Width
12" - 90"
Valance Headrail Dimension
4 5/8" D x 5" H
Minimum Mounting Depth
3"
Minimum Flush Mounting Depth
4 5/8"
Cassette Headrail
The cassette headrail comes with a matching fabric strip.
Width
12" - 84"
Height
12" - 90"
Cassette Headrail Dimension
4 1/4" D x 3 5/8" H
Minimum Mounting Depth
1 3/4"
Minimum Flush Mounting Depth
4 1/4"
Mounting Details
Top or Wall Mounted only
Other
Cassette fabric is not oriented to the shade fabric (e.g., on a patterned fabric, the pattern of the shade fabric and that of the cassette fabric may not necessarily align)
Contour Fabric Valance
The Fabric Valance is 4.5" tall and it is wrapped with the same color fabric used on the shade. Its fabric wrapped design provides a polished and modern appearance while also effectively covering the roller.
Width
12" - 94"
Height
12" - 108"
Minimum Mounting Depth
3 1/2"
Minimum Flush Mounting Depth
4 3/8"
Other
Valance fabric is not oriented to the shade fabric (e.g., on a patterned fabric, the pattern of the shade fabric and that of the valance fabric will not necessarily align)
Material
Contoured PVC valance. Fabric covered to match shade. The spline and returns are color coordinated.
Guaranteed to Fit
Let us take the worry out of measuring. Upgrade with our Guaranteed to Fit protection. If your blind doesn't fit we will remake it for you.
If you make a mistake, we've got you covered. learn more
If you make a mistake, we've got you covered. learn more
Charger
Used to re-charge the batteries for a motorized shade. One charger can be used for multiple motorized shades so you may buy just one per order but you can always buy extra. If you select motorization we recommend adding at least one charger.
Details
Charger cable is 6ft. long.
Charger has an LED that tuns red to indicate charging and green to indicate fully charged.
No Remote - Use Phone as Remote
A free motorization app you can downloaded on your mobile device from the IOS App Store or Google Play to operate the shades. Please note that you must be within range to operate the shades with phone. The app will vary by product, please see Bluetooth Motorization specifications below for the App used.
Remote - 1 Channel
Control a single window shade or a group of window shades at ONCE. Single channel remote will only operate multiple shades together, not individually.
Details
Control single shades or a group of shades simultaneously.
Color
White
Other
Includes convenient mounting hardware.
Remote - Premium 12 Channel
12-channel remote, controls up to 24 shades. Control single shades on each channel or group shade performing the same function.
Details
Controls up to 24 shades.
Control single shades on each channel or group shade performing the same function.
Control single shades on each channel or group shade performing the same function.
Other
Includes convenient mounting hardware.
Color
White
Bali Gateway Smart Home Hub
Adding a Smart Home Hub to motorized blinds allows you to connect your window coverings to your smart home such as Alexa or Google Home. One Smart Home Hub system will allow you to control multiple blinds and in most cases your entire home depending on your home size.
We also recommend ordering at least one remote as well with your blinds for configuration purposes.
We also recommend ordering at least one remote as well with your blinds for configuration purposes.
Brand
Bali
Mobile App
Bali Motorization App
Amazon Alexa Compatible
Yes
Google Home Compatible
Yes
Apple HomePod Compatible
Yes
Other
Controls up to 30 Z-wave devices (shade motors and remotes)
Average Home Coverage
Appox. 2,500 square feet depending on a variety of factors including number of walls and material of walls.
Instructions
Free Features
Roll Position
Roll position determines which side the fabric unrolls from and whether the roller tube is visible from inside your home. With a standard roll, the fabric drops behind the roll (closest to the window), and the roll is visible from the room. This option keeps the fabric tighter to the wall on an outside mount.
With a reverse roll, the fabric drops in front of the roll, which helps hide the roller tube from the room side of the shade.
With a reverse roll, the fabric drops in front of the roll, which helps hide the roller tube from the room side of the shade.
